Product Details
- Place of Origin: Tangshan,China
- Brand Name: KOHS
- Model Number: K-005
| Brand | KOHS | |
| Type | Ceramic Crucible | |
| Material | 99.5%Alumina Ceramic | |
| Color | Ivory | |
| Dimensions | Upside Diameter | 35mm |
| Height | 65mm | |
| Wall Thickness | 2.5mm | |
| Content | 45ml | |
| Long-term Operating Temperature | 1650oC or 3002 °F | |
| Tolerance | ±0.3mm | |
| Package | Bubble Wrap EPS Carton Wooden Box | |
- Place of Origin: Tangshan,China
- Brand Name: KOHS
- Model Number: K-005
Conical Crucible | |||||
Upside Dia. | Under Dia. | Height | Wall Thickness | Content | Weight |
25 | 18 | 22 | 1.3 | 5 | 0.01 |
28 | 20 | 27 | 1.5 | 10 | 0.02 |
32 | 21 | 35 | 1.5 | 15 | 0.025 |
35 | 18 | 35 | 1.7 | 20 | 0.03 |
36 | 22 | 42 | 2 | 25 | 0.036 |
39 | 24 | 49 | 2 | 30 | 0.04 |
52 | 32 | 50 | 2.5 | 50 | 0.05 |
61 | 36 | 54 | 2.5 | 100 | 0.1 |
68 | 42 | 80 | 2.5 | 150 | 0.15 |
83 | 48 | 86 | 2.5 | 200 | 0.18 |
83 | 52 | 106 | 2.5 | 300 | 0.25 |
86 | 49 | 135 | 2.5 | 400 | 0.3 |
100 | 60 | 118 | 3 | 500 | 0.4 |
88 | 54 | 145 | 3 | 600 | 0.44 |
112 | 70 | 132 | 3 | 750 | 0.5 |
120 | 75 | 143 | 3.5 | 1000 | 0.7 |
140 | 90 | 170 | 4 | 1500 | 1.1 |
150 | 93 | 200 | 4 | 2000 | 1.4 |
